H2Optics Exposed Urinal Flush Valve - Chrome 81T231BTA Delta Commercial

Delta Commercial SKU: 81T231BTA
Finish - Chrome
Save $-730.28
/
10 available for immediate shipping.
Select My Store to view local stock.
Free Shipping Over $50*
Nationwide Reach
Easy Returns
Price Match Promise
Save $-730.28
/
Product Image
H2Optics Exposed Urinal Flush Valve - Chrome 81T231BTA Delta Commercial
Save $-730.28
/
Often bought with
81T231BTA product image.
81T231BTA product image.
Delta Commercial 81T231BTA
6581001.020 product image.
6581001.020 product image.
American Standard 6581001.020
6590001.020 product image.
American Standard 6590001.020
1955SSCT 000 product image.
1955SSCT 000 product image.
Bemis 1955SSCT 000
Total Price : $1,346.19
81T231BTA product image.
81T231BTA product image.
Delta Commercial 81T231BTA
6581001.020 product image.
6581001.020 product image.
American Standard 6581001.020
6590001.020 product image.
American Standard 6590001.020
1955SSCT 000 product image.
1955SSCT 000 product image.
Bemis 1955SSCT 000
Total Price : $1,346.19
Total Price : $1,346.19
More from 81TBT series
81T231BTA product image.
81T231BTA product image.
Delta Commercial 81T231BTA
81TBT
Flushometer Flush Valves
81T201BTA product image.
81T201BTA product image.
Delta Commercial 81T201BTA
81TBT
Flushometer Flush Valves
81T231BTA product image.
81T231BTA product image.
Delta Commercial 81T231BTA
81TBT
Battery flush valve for 3/4" top spud flushing URINAL with H2Optics® SENSOR ON VALVE - maximum 13" height (c/l of inlet to top of urinal)
  • External water conserving adjustment: Factory Set to 1.9L(0.50 Gal.) - FIELD ADJUSTABLE from 0.47 to 3.78 Litre Flush (1/8 to 1.0 GAL.)
  • Chloramine resistant diaphragm
  • Electronic operated non-hold-open metal override button with 5 second lockout
  • Scratch resistant replaceable lens window
  • Polished chrome plated body.
  • Adjustable 121mm (4-3/4") plus or minus 11mm (7/16") inlet/valve outlet centers
  • ADA compliant, automatic operation battery powered infrared sensor
  • Four (4) size AA alkaline batteries factory installed with valve in sleep mode for easy installation
  • Infrared sensor range adjustment of 203mm-610mm (8"-24"), factory set at 16" (±2")
  • Quiet action, TECK® exposed diaphragm flush valve
  • Right or left-hand supply installation
  • 6 VDC input, 6 second arming delay
  • Brass diaphragm retainer
  • Renewable seat
  • Polished chrome plated vandal resistant metal cover with top mounted sensor operated H2Optics® electronics
  • Hinged battery housing for easy maintenance
  • Vacuum breaker
  • Set-up sensor range adjustment indicator lights
  • Optional 24 hour automatic flush factory set to off
  • Low battery flashing light (5000 flushes remaining) with battery strength indicator
  • 3/4" copper sweat inlet
  • Adjustable flow
  • Battery operated, batteries included
  • Electronic exposed flush valve
  • Hands-free operation
  • Urinal, 13" height
  • For 3/4" top spud urinal fixture
  • Body mounted sensor
Specifications

Attributes & Dimensions
SKU 81T231BTA
Splashes Part ID 6547094
UPC 055870349438
Brand Delta Commercial
Series 81TBT
Product Type Flushometer Flush Valves
Finish Chrome
Flush Valve Type Automatic
Item Weight 8.785 lb.
